| Standard | Monel K500 |
| UNS | N05500 |
| WERKSTOFF NR. | 2.4375 |
Monel K500 ANSI B16.5 / B16.47 Flanges Specification :
Standard : ASTM, ASME, ANSI, JIS, DIN, BSNA 11, EN Ni 99.2, JIS NW 2200, GOST-НП-2
Dimensions : ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Designation : ASTM / ASME B 564 / SB 564
Class : Class 150, Class 300, Class 400, Class 600, Class 900, Class 1500 & Class 2500
Size : 1/2″NB TO 60″NB
Grades : Monel (UNS No. N05500) Flanges, 2.4375
Pressure : DIN PN6, PN10, PN16, PN25, PN40, PN64, PN100, PN16
Monel 2.4375 Shim Stock Chemical Composition
| S | C | Cu | Mn | Fe | Si | Ni |
|---|---|---|---|---|---|---|
| 0.010 maximum | 0.25 maximum | 027.00 – 033.00 | 1.5 maximum | 0.5 – 02 | 0.5 maximum | o63.00 min |
ASTM B127 Monel K500 Sheet Mechanical Properties
| Ultimate Tensile | Elong. | Yield Properties | Rockwell Hardness C, min. | Hardness Brinell 3000 kg, min. | |
|---|---|---|---|---|---|
| Cold Worked/SR Over 1(25.4) to 3 | |||||
| Min | 100 KSi | 140 KSi | 17.0 | 29 | 280 |
| Max | |||||
| Min | 690 MPa | 965 MPa | |||
| Max | |||||
| Aged / Hot Worked Hardened | |||||
| Min | 100 KSi | 140 KSi | 20.0 | 27 | 265 |
| Max | |||||
| Min | 690 MPa | 965 MPa | |||
| Max | |||||
