| Standard |
ASTM B637 / ASME SB637 |
| Bolt / Screw Size |
M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Nuts Size |
M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Washers Size |
M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Machine Screws Size |
M1.6 – M12 |
| Self Tapping Screw Size |
No.2 – No. 14 |
| Length |
3 mm to 200 mm |
| Threads |
UNF, BSW, BSF, METRIC, UNC, or as required |
| Fasteners |
- DIN : DIN 934, DIN 931, DIN 970, DIN 933
- UTS : UNEF, NPT, UNC, UNS, UNF, NPTF
- ISO : JIS standards, ISO 4033, ISO 4032,
- ANSI – American National Standards Institute
- ASME B18.5
- ANSI B 28.2.4 1M
- as per defined in ASME B16.5 standard Stud Bolt length
- ANSI B 18.2.4 2M
- as per defined in ASME B18.2.2 Hex nuts
|
| Form |
Hex, Threading, Square, Round as per Gauge Etc. |
| Raw materials Source |
JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Threads Configuration |
ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification |
Dual Certified As per ASTM & ASME Codes |
| Dimensions |
DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Threads |
Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate |
as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications |
PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production Process |
M24-M100: hot forging , M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Types |
Bolts, Nuts, Stud Bolts, Washers, Threaded Rod, Anchor Fasteners, Eye Bolt, Stud, Cotter Pin, Socket Screw, Fine Fasteners & Spares, Foundation Fasteners, Hexagon Castle Nuts, Hexagon Domed Cap Bolts, Hexagon Thin Nuts etc. |
